Translumina Products

Chrome PC Sirolimus Eluting CoCr Stent

  • CoCr Coronary Stent System
  • Unique microporous surface
  • Maximum flexibility due to 2-Connector-Design
  • Excellent Side Branch access
  • Strut thickness 68 µm
  • Cobalt Chromium alloy
  • 5 Years Long term clinical follow-up
  • Biodegradable Polymer DES (PLA)

Yukon Choice PC Sirolimus Eluting Stent

  • Biodegradable Polymer DES
  • 50% reduction in definite stent thrombosis (VLST)
  • 78% reduction in very late stent thrombosis (VLST)
  • Microporous stent surface
  • Excellent flexibility
  • The plattform Yukon Choice PC is recommended by the latest European Society of Cardiology (ESC) guidelines for myocardial revascularization

Cathy N.4 PTCA Dilatation Catheter

  • Trackability and pushability in balance
  • Perfect product balance with soft and hard high-tech materials
  • New designed luer
  • New distal shaft for high manoeuvrability
  • New flexible tip – easy access to all lesions

SIS Medical Products

Tin High Performance PTCA Balloons

  • Low compliant, low profil for easy lesion crossing
  • High pressure PTCA Balloon
  • RBP: 20atm
  • Long tapered tip (4mm)
  • Lesion entry profil: 0.016’’
  • Excellent trackability
  • Min. Guiding Catheter 5 F

BEO NC Low Profile High Pressure PTCA Balloons

  • Unique two-step tip design with red (soft) and intermediate (yellow) part for better trackability and a better crossing of stent struts.
  • Excellent lesion crossing profil (0.022’’ for BEO NC 1.5 – meassured on the ballon platin marker)
  • High rated burst pressure (RBP) 24atm
  • low compliance with linear compliance curve over a wide pressure range (nominal 10atm – RPB 24atm)
  • Min. Guiding 5F
  • For Kissing – Balloon technique : 6F Min. guiding for a combination of all balloon diameters (1.5mm – 4.5mm)
  • Two platinum marker for the sizes 2.0mm – 4.5mm, one central marker for the size 1.5mm

OPN NC Super High Pressure PTCA Balloons

  • Reaching pressure up to 45ATM + Inflation Devices (55 ATM Pressure)
  • Twin layer balloon construction with virtually zero dog – boning effect
  • Super high pressure PTCA balloon (RPB 35atm)
  • Long tapared tip design for a better cross ability
  • Better crossing profile (0.028’’ 2.0mm) than scoring – and cutting balloons
  • Min. guiding catheter: 5F
  • Two platinum markers for all sizes: available from 1.5 – 4.5mm diameter
  • Linear compliance curve up to over 40atm

Xtrac EC Aspiration Catheters

Key Features:

  • Easy and fast placement provided by a long, hydrophilic coated rapid exchange part (25 cm) and a supporting stylet which is significantly improving the pushability and kink restistance of the catheter.
  • Precise positioning supported by very good visibility of tip marker 3 mm from the distal, atraumatic catheter end.
  • Large aspiration lumen providing a high aspiration capacity.
  • Large and eliptical aspiration hole shape facilitating the entry of large pieces of thrombus.
  • 60 ml syringe saving time and increasing aspiration effectiveness.

Specifications:

  • Long rapid exchange part for better trackability (25cm)
  • Supporting stiffening stylet – for a high pushability and kink restictance of the catheter
  • Hydrophilic coating on the distal 25cm of the catheter
  • Large aspriation lumen providing a high aspiration capacity (6F inner lumen: 0.041’’ and 7F inner lumen 0.053’’)
  • Total lengh: 145cm
  • Distal radioparque marker: 3mm from distal tip
  • 6F compatible with 6F Guiding Catheter
  • 7F compatible with 7F Guiding Catheter

Indications:

Thrombus aspiration for coronary arteries

Experience:

  • Very fast thrombus aspiration (60ml syringe saving time)
  • Highly kinik – resistant
  • very good trackability
  • Easy access to distal vessel anatomy

Easy T New High Performance PTCA Dilatation Catheter

  • Short tapered Tip design
  • High rated burst pressure (21atm)
  • Low compliance
  • Hydrophilic coating on Balloon and distal Shaft (1.5mm – 2.5mm) for less friction
  • New distal chaft design for better trackability
  • New HUB / Luer – Design providing better handling and easy identification of Balloon size, diameter and length
  • Min. Guiding 5F
  • Kissing Balloon technique: 6F Min. Guiding for a combination of all Balloon diameter (1.5mm-4.5mm)
  • Diameter : 1.5 – 4.5mm (2 platin markers for all sizes)
  • Length : 6mm, 10mm, 15mm, 20mm, 25mm, 30mm

Indications:

  • For predilation and postdilation
  • Excellent in crossing stent struts
  • For the proximal optimizing technique (POT) with the very short length of 6mm
  • For tortuous vessel anatomy

Experience:

  • Very good trackability and pushability even in tortuous vessel anatomies
  • Less vessel friction
  • Better results in pre- and postdilatation in combination with DES (drug eluting Stents)
  • OCT proven better apposition of stent struts
Rocket_Curve_Web

NIC 1.1 Hydro PTCA Balloon

Complete hydrophilic coating (balloon + shaft) 1.1 x 6 mm

Specifications:

  • Small balloon diameter 1.1mm at nominal pressure
  • High rated burst pressure (RBP) 21atm
  • low compliance
  • Lesion Crossing Profil: 0.0205”
  • Hydrophilic coating on Balloon and distal Shaft
  • New HUB / Luer – Design proving better handling and easy identification of Balloon type, diameter and length
  • Unique tapered tip
  • 1 single central – marker
  • Min. Guiding: 5F
  • Diameter: 1.1mm
  • Length: 6mm, 10mm, 15mm, 20mm

Indications:

  • Successful treatment of subtotal occlusions or even CTO’s (chronical total occlusions)
  • or excellent predilation of tightest lesions
  • For overstented side – branches
  • For expanding stent – cells
  • Instead of using microcatheter

Experience:

  • Better crossing of very small lesion diameters (CTO’s) compaired to other balloons
  • hydrophilic coating proving excellent crossability in tightest lesions
  • low compliance and high pressure resistance for successful predilation of calcified lesions where force and safety is needed
NIC-1.1-x-12_A_Grey_RocketV5

NIC Nano Hydro PTCA Balloon

The combination of an Ultra low Profil, excellent trackability and hydrophilic coating are key to a successful Treatment of tightest lesions and CTO’s – 0.85 x 6 mm

Specifications:

  • Smallest crossing profil on the market 0.0195”
  • Proximal single – marker position – for better crossability of stent struts and total occlusions
  • Hydrophilic coating on Balloon and distal Shaft
  • New HUB / Luer – Design proving better handling and easy identification of Balloon type, diameter and length
  • Min. Guiding: 5F
  • Crossing profil: 0.0195’’
  • High rated burst pressure: 21atm
  • Low compliance
  • Diameter: 0.85mm
  • Length: 6mm, 10mm, 15mm

Indications:

  • Successful treatment of CTO’s (chronical total occlusions)
  • The balloon of choice prior to the use of a rotablator
  • Recrossing of overstented side – branches
  • Guide wire support

Experience:

  • Better crossing of subtotal and total occlusions (CTO’s) than other balloons
  • Successfully used to cross overstented side – branches
  • High pressure resistant

Eurocor Products

Peripheral Products

  • Freeway 014 PTA Balloon Catheter (Drug Eluting Balloon)
  • Freeway 035 PTA Balloon Catheter (Drug Eluting Balloon)
  • Joker 014 PTA Balloon Catheter (OTW PTA Balloon Catheter)
  • Joker 035 PTA Balloon Catheter (OTW PTA Balloon Catheter)
  • Freeway Shunt Balloon Catheter

Paclitaxel –Eluting Coronary Balloon Dilatation Catheter

DIOR PTCA Catheter is explained as a double Lumen coronary Catheter for a rapid exchange with a balloon that can be enlarged and two radiolucent targets (proximal and distal), to facilitate the balloon positioning under X-Ray fluoroscopy. DIOR PTCA Catheter is coated with Paclitaxel pharmaceutical active ingredients

Lepu Medical Products

Introducer Kits

Brilliant Introducer Kits

Patented hydrophilic coating guarantees the smooth transition and smoother navigation.

Advanced material improves bendability and flexibility without gapping or kinking.

Quarter-turn-screw dilator locking system ensures the smooth transition from dilator to sheath, and prevents the pull out of the dilator because of the friction during insertion.

Minimized possibility of damaging tissue upon sheath entry, advancement and withdrawal, providing smoother and easier vascular access even through difficult access sites.

Shoocin Introducer Kits

Advanced material improves bendability and flexibility without gapping or kinking.

Quarter-turn-screw dilator locking system ensures the smooth transition from dilator to sheath, and prevents the pull out of the dilator because of the friction during insertion.

Minimized possibility of damaging tissue upon sheath entry, advancement and withdrawal, providing smoother and easier vascular access even through difficult access sites.

Shoocin Introducer Kits

Radial Artery Compression Tourniquets

  • Specially designed for radial artery hemostasis of post percutaneous puncture.
  • Transparent material ensures clear visual control of hemostasis procedure.
  • Unilateral valve connected to the balloon allows of accurate pressure adjustment to provide personalized hemostasis procedure.
  • Adjustable band length is convenient to fit for patient’s comfort.
  • Stopcock on syringe helps with easy and accurate deflation.

Manifolds

  • Visible handle makes the flow control easy and accurate.
  • On / Off types are available for different user habits.

Inflation Device

  • Fluorescence clock face for clearer display.
  • Smooth fine adjustment for accurate inflation.
  • Barrier screw pivot provides precise pressure placement.
  • The internal multi-buckle structure ensures more secure lock.
  • Ergonomic grip fits comfortably in either hand.
  • Petal-shaped handle ensures torque control without slipping.

Angiography Control Syringes

  • Solid and smooth plunger with unique push button make it easy for operation.
  • Clear scale ensures accurate control of infusion volume.
  • Latex free.

Y-Hemostasis Valve Sets

  • Effectively minimize blood loss and provide a smooth channel for interventional device delivery.
  • Easy push-pull mechanism allows to operate with one hand.
  • Push-pull/Rotating type

Alvimedica Products

Alviguide Blue+ Coronary Guiding Catheter

  • Coronary guiding catheters offering excellent torque and kink resistance, enabling fast and effective procedures.
  • Outstanding torque control and kink resistance for an easier catheter positioning and handling
  • Excellent curve retention and back-up support for challenging procedures
  • Large inner lumen and wide variety of shapes to meet all requirements
Alviguide Blue+ Coronary Guiding Catheter

Alvision Coronary Angiographic Catheter

  • Coronary angiographic catheters designed for effective diagnostic procedures.
  • Outstanding torque response and catheter stability due to Flat Wire Braid design
  • Large inner lumens allow for superior visualization
  • Wide choice of shapes to master every challenge
Alvision Coronary Angiographic Catheter

Cre8BTK Amphilamus Eluting Balloon Expandable Stent

Polymer-free Amphilimus™ eluting stent for below the knee arteries. The absence of the polymer minimizes the risk of inflammation/thrombosis, while the propriety formulation enhances drug absorption. This may contribute to maximize results in diabetic patients.

  • Controlled and directed drug elution as a result of the Abluminal Reservoir Technology
  • Optimal efficacy achieved through an homogeneous drug distribution and improved bioavailability due to the proprietary Amphilimus™ formulation, which is the combination of Sirolimus and an organic acid
  • Proven bio and haemo-compatibility enabled by the Bio Inducer Surface coating, which accelerates the rate of endothelization and reduces thrombogenicity

Isthmus Logic CoCr Balloon Expandable Stent

  • Isthmus Logic is a Cobalt-Chromium stent with Bio Inducer Surface technology for the treatment of iliac vessels.
  • Proven bio and haemo-compatibility enabled by the Bio Inducer Surface coating, which accelerates the rate of endothelization and reduces thrombogenicity
  • Uniform radial force and excellent scaffolding with an unique cell architecture
  • Platinum markers and no stent foreshortening allow unmatched placement accuracy and visualization.
Isthmus Logic CoCr Balloon Expandable Stent

Easy Flype Self Expandable Stent

  • Easy Flype is a dedicated self expanding stent with hybrid cell design maximizing flexibility and conformability in SFA.
  • Proven bio and haemo-compatibility enabled by the Bio Inducer Surface coating, accelerating strut coverage, reducing thrombogenity and sealing against heavy metal ions release.
  • Effective balance between flexibility (for optimal conformability) and radial force (for highly calcified vessels), available up to 150mm in length.
  • Superior track and high precision upon stent release provided by a unique single-hand delivery system
